The SMDA-NK250 Fully Automatic 2-Lane NG/OK Loader is designed for high-efficiency PCB handling in SMT production environments.
It supports dual-lane operation for simultaneous sorting of NG and OK boards, optimizing throughput and line balance. With a fast PCB loading time of approximately 6 seconds, the system ensures minimal cycle delays.
It accommodates PCB thicknesses starting from 0.6 mm and handles a wide size range from 50 × 50 mm up to 455 × 330 mm.
Precision alignment and stable transfer mechanisms ensure reliable board handling, while its automated sorting logic enhances production accuracy.
The SMDA-NK330 is ideal for high-mix, high-volume manufacturing lines requiring consistent performance and reduced manual intervention.
Specifications
| PCB loading time |
~6 seconds |
| PCB Thickness |
Min. 0.6 mm |
| PCB Size |
50 x 50 mm up to 455 x 330 mm |
| |
| Dimensions |
191 x 158 x 124 (h) cm |
| Weight |
360 kg |
| Packaging |
The NK330 is shipped per crate |
| Included |
Including 4 cassettes/magazines |
| Shipping dimensions |
195 x 161 x 120 (h) cm |
| Shipping weight |
430 kg |
